FRONT DISC
Outer diameter : 250mm
Internal diameter : 118mm
Diameter of center-to-center of rotor-hat mounting holes:134mm
Hole diameter : 6.5mm
Thickness : 3.0mm
Number of holes : 6
Material:Stainless SUS410
Front Brake Pad:SPF204-135
REAR DISC
Outer diameter : 220mm
Internal diameter : 118.2mm
Diameter of center-to-center of rotor-hat mounting holes:134mm
Hole diameter : 6.5mm
Thickness : 4.0mm
Number of holes : 6
Material:Stainless SUS410
Rear Brake Pad:SPR302-152
